Grove All Terrain Cranes

• Capacity:50 t
• Main boom: 10.2 m – 40.0 m
• Maximum jib:15.0 m
• Maximum tip height:60.7 m

The NEW GMK3050-2 features a five section 40m. Twin-Lock hydraulic pinned main boom and an extra 7m swing-away jib. Its very compact dimensions with all equipment on board, guarantee a fast set-up and immediate readiness, even on the smallest job sites. The CCS operating system with jog-dial for efficient and comfortable operation and the boom configurator mode ensures the best boom configuration and utilisation.

• Capacity: 60 t
• Main boom: 9.7 m – 48.0 m
• Maximum jib: 15.0 m
• Maximum tip height: 65.0 m

The NEW GMK3060L all-terrain mobile crane combines a powerful, seven-section MEGAFORM boom with a compact three-axle carrier, making it ideal for a variety of work in tight locations. This crane features Manitowoc's new standardized Crane Control System with boom configurator mode for fast and efficient set-up.

• Capacity: 60t
• Main boom: 9.7 m – 43.0 m
• Max jib: 15.0 m
• Max tip height: 60.7 m

The NEW GMK3060 all-terrain crane combines a powerful, six-section MEGAFORM™ boom with a compact three-axle carrier, making it ideal for a work in tight locations. Taxi crane weight, roadable with 12t per axle (includes 6.6t c/w, 15m fly and equipment box). This mobile crane is also one of the first to feature Manitowoc's new standardised Crane Control System.

• Capacity: 80 t
• Main boom: 11.0 m – 51.0 m
• Maximum jib: 21.0 m
• Maximum tip height: 75.0 m

This grove crane features a compact design combined with superior strength. The new GMK4080-2 will let you dominate with performance capabilities that include best load charts in its class.

• Capacity: 90 t
• Main boom: 11.0 m – 51.0 m
• Max jib: 8.7 m – 21.0m
• Max tip height: 75.0 m

Features a compact design combined with superior strength, with 3.5t more counterweight than the GMK4080, this increases lift capacity by 10t. The new GMK4090 lets you dominate the competition with performance capabilities that include best load charts in its class.

• Capacity: 100 t
• Main boom: 11.4 m – 60.0 m
• Max jib: 11.0 m – 25.6 m
• Max tip height: 89.0 m

Its superior axle weight distribution of12t per axle, 4.9t chart, rooster, single sheave hook, equipment box with timber/chains (approx. 300kg), secondary retarder, and 100t lift capacity provides the best load charts in its class. Easily permitted, and able to road 6.7t of counterweight. This mobile crane is designed for narrow job sites, limited lift areas, and with its 60m boom, it can reach over buildings and structures to get the job done.

• Capacity: 150 t
• Main boom: 12.8 m – 60.0 m
• Max jib: 33.8 m
• Max tip height: 88.0 m

Biggest capacity crane in QLD without a dolly!

The new GMK5150-L deliver great ROI due to outstanding lifting capacities and greater job site accessibility and roadability. Impressive lifting, transport to site, job site maneuverability, and fuel efficiency help you achieve greater margins.

Please Note: No dolly is required in Queensland on class 2 permit (second winch, hook, and rear mounted timber/chain box).

> Download GMK5150L product guide

• Capacity: 180 t
• Main boom: 13.7 m – 64.0 m
• Max jib: 34.0 m
• Max tip height: 101.0 m

This is a versatile model with the added logistical benefits with interchangeable counterweight slabs and self-rigging auxiliary hoist. The GMK 5180-L has proven lower operating costs when compared to other cranes in its class, with 30% less diesel consumption on the driveline.

• Capacity: 200 t
• Main boom: 13.7 m – 64.0 m
• Max jib: 34.0 m
• Max tip height: 101.0 m

Logistical benefits due to interchangeable counterweight slabs and self-rigging auxiliary hoist. Lower operating costs due to 30% less diesel consumption on the driveline.

• Capacity:250 t
• Main boom:13.4 m – 78.5 m
• Maximum jib: 37.0 m
• Maximum tip height: 115.0 m

With the longest boom and large capacity combined with a small footprint and excellent manoeuvrability, the new GMK5250XL-1 challenges the performance capabilities of other mobile cranes in its class. The Grove single engine design, with the latest emission levels, reduces the operating costs through 30% lower diesel consumption compared to previous generation models.

• Capacity: 250 t
• Main boom: 13.3 m – 70.0 m
• Max jib: 37.0 m
• Maxi tip height: 110.0 m

The most powerful, versatile five-axle grove crane available, the new GMK5250-L has performance capabilities that include the highest-rated capacity, best load chart in its class, best maneuverability, quickest set-up time and most operator comfort and convenience.

• Capacity: 300 t
• Main boom: 15.6 m – 80.0 m
• Max jib: 37.0 m
• Max tip height: 120.0 m

From urban job sites to rough terrain, the GMK6300-L mobile crane continues to be a global success. Featuring the latest steer-by-wire technology and patented MEGATRACK™ system, the GMK6300L has a large lifting capacity for its compact design, maintaining its versatility for the operator.

• Capacity: 400 t
• Main boom: 15.4 m – 60.0 m
• Maximum jib: 79.0 m
• Max tip height: 137.0 m

With the best load chart in class, the GMK6400 continues to be one of the most successful cranes of the Grove GMK all-terrain crane range with innovations like the removable outrigger box and self-rigging auxiliary hoist. it also the trademarked and self–rigging MegaWingLift™ attachment lifts the already impressive capacity by nearly 70 percent.

• Capacity: 450 t
• Main boom: 16.0 m – 60.0 m
• Max jib:  79.0m
• Max tip height: 136.0 m

The GMK7450 offers a 450t maximum capacity on a seven-axle carrier with a 60m Twin-Lock boom. The optional Mega-Wing-Lift attachment increases capacity throughout the working range. The fully automatic ALLISON transmission, combined with MEGATRAK™ independent suspension system, ensures optimal performance both on and off-road.

• Capacity:300 t
• Main boom:15.6 m – 80.0 m
• Maximum jib:37.0 m
• Maximum tip height:120.0 m

The Grove GMK6300L-1 is stronger than the GMK6300L. Improved load charts, especially on long boom applications and large lifting capacities, are the main advantages of this crane compared to the GMK6300L. Further benefits of Grove’s GMK6300L-1 include increased working radius and capacities when working at height. A Euromot 4-/EPA Tier 4 final engine helps improve fuel economy. The GMK6300L-1 delivers versatility and efficiency, no matter the job.

• Capacity:70t
• Main boom: 60m
• Maximum jib: 8,7 - 15m
• Maximum tip height: 77m

The GMK4070L offers with 60m the longest boom while also being the lightest crane in its class. Within 10t per axle the crane can carry 5,2t of counterweight and within 12t per axle 13,3t which leads to an unmatched flexibility in transportation. In addition to that the GMK4070L dominates with unmatched lifting capacities with full and partial counterweight configurations.
